OnePlus Ace 2
- Screen: 6.74" AMOLED - 1240 x 2772
- SoC: Qualcomm Snapdragon 8 Plus Gen 1
- Camera: 3 (50 MP + 8 MP + 2 MP)
- Battery: 5000 mAh
- OS: Android 13
- Weight: 204 grams (7.2 oz)
Review
Scores marked with a red asterisk (
*
) are approximate, as we currently do not have sufficient test results to make a precise estimation.
We may receive a commission from Amazon for purchases made using the links below, but this has no bearing on our assessment methodology.
Full specifications
Detailed specifications, tests, and benchmarks of the OnePlus Ace 2Display
| Type | AMOLED |
| Size | 6.74 inches |
| Resolution | 1240 x 2772 pixels |
| Aspect ratio | 20.1:9 |
| PPI | 450 ppi |
| Refresh rate | 120 Hz |
| Adaptive refresh rate | Yes |
| Max rated brightness | 500 nits |
| Max rated brightness in HDR | 1450 nits |
| HDR support | Yes, HDR10+ |
| Screen protection | Tempered glass |
| Screen-to-body ratio | 90% |
| Display features |
- DCI-P3
- Always-On Display - DC Dimming |
Design and build
| Height | 163.4 mm (6.43 inches) |
| Width | 74.3 mm (2.93 inches) |
| Thickness | 8.7 mm (0.34 inches) |
| Weight | 204 g (7.2 oz) |
| Waterproof | No |
| Advanced cooling | Vapor chamber |
| Rear material | Glass |
| Frame material | Metal |
| Colors | Black, Blue |
| Fingerprint scanner | Yes, in-display |
Performance
| Chipset | Qualcomm Snapdragon 8 Plus Gen 1 |
| Max clock | 3190 MHz |
| CPU cores | 8 (1 + 3 + 4) |
| Architecture |
- 4 cores at 2 GHz: Cortex-A510
- 3 cores at 2.75 GHz: Cortex-A710 - 1 core at 3.2 GHz: Cortex-X2 |
| L3 cache | 6 MB |
| Lithography process | 4 nanometers |
| Graphics | Adreno 730 |
| GPU shading units | 1536 |
| GPU clock | 900 MHz |
| FLOPS | ~2764.8 GFLOPS |
Benchmarks
| CPU | 331367 |
| GPU | 439450 |
| Memory | 218987 |
| UX | 253303 |
| Total score | 1235815 |
| Stability | 73% |
| Graphics test | 61 FPS |
| Graphics score | 10297 |
Memory
| RAM size | 12, 16 GB |
| Memory type | LPDDR5X |
| Channels | 4 |
| Storage size | 256, 512 GB |
| Storage type | UFS 3.1 |
| Memory card | No |
Software
| Operating system | Android 13 |
| ROM | ColorOS 13.1 |
Battery
| Capacity | 5000 mAh |
| Max charge power | 100 W |
| Battery type | Li-Po |
| Replaceable | No |
| Wireless charging | No |
| Reverse charging | No |
| Fast charging | Yes (50% in 9 min) |
| Full charging time | 0:26 hr |
Camera
| Matrix | 50 megapixels |
| Image resolution | 8192 x 6144 |
| Zoom | Digital |
| Flash | LED |
| Stabilization | Optical |
| 8K video recording | No |
| 4K video recording | Up to 60FPS |
| 1080p video recording | Up to 60FPS |
| Slow motion | 480 FPS (720p) |
| Angle of widest lens | 120° |
| Lenses | 3 (50 MP + 8 MP + 2 MP) |
| Wide (main) lens |
- 50 MP
- Aperture: f/1.8 - Focal length: 24 mm - Pixel size: 1 micron - Sensor: 1/1.56", Sony IMX890 (Exmor-RS CMOS) - Phase autofocus - Optical stabilization |
| Ultra-wide lens |
- 8 MP
- Aperture: f/2.2 - Focal length: 16 mm - Pixel size: 1.12 micron - Sensor: 1/4.0", Omnivision OV08D10 (CMOS) |
| Macro lens |
- 2 MP
- Aperture: f/2.4 - Pixel size: 1.75 micron - Sensor: 1/5", Omnivision OV02B10 (CMOS) |
| Camera features |
- Bokeh mode
- Pro mode |
| Megapixels | 16 megapixels |
| Image resolution | 4608 x 3456 |
| Aperture | f/2.4 |
| Focal length | 26 mm |
| Pixel size | 1 microns |
| Sensor type | ISOCELL CMOS |
| Sensor size | 1/3.09" |
| Video resolution | 1080p (Full HD) at 30 FPS |
Connectivity
| Wi-Fi standard | Wi-Fi 6 (802.11 a/b/g/n/ac/ax) |
| Wi-Fi features |
- Dual Band
- Wi-Fi MiMO - Wi-Fi Direct - Wi-Fi Hotspot - Wi-Fi Display |
| Bluetooth version | 5.3 |
| Bluetooth features | LE |
| USB type | USB Type-C |
| USB version | 2 |
| USB features |
- Charging
- USB-Storage mode - OTG |
| GPS | GPS, GLONASS, Beidou, Galileo, QZSS |
| NFC * | Yes |
| Infrared port | Yes |
| Number of SIM * | 2 |
| Type of SIM card | Nano |
| Multi SIM mode | Standby |
| eSIM support * | No |
| Hybrid slot | No |
| LTE Cat * | 18 |
| 2G network | GSM 850/900/1800MHz |
| 3G network | UMTS(WCDMA) bands 1/4/5/8 |
| 4G network | LTE bands 1/3/4/5/8/28A/34/38/39/40/41 |
| 5G support | Yes |
Sound
| Speakers | Stereo |
| Headphone audio jack | No |
| FM radio | No |
| Dolby Atmos | Yes |
Other
| Category | Flagship |
| Announced | February 2023 |
| Release date | February 2023 |
| Sensors |
- Proximity sensor
- Gyroscope - Accelerometer - Ambient light sensor - Compass - Fingerprint |
| Bundled charger | Yes, 100 W |
*
Disclaimer!
Some specifications of the Ace 2 may differ by country or region
