Samsung Galaxy Z Flip 5
- Screen: 6.7" Dynamic AMOLED - 1080 x 2640
- SoC: Qualcomm Snapdragon 8 Gen 2
- Camera: 2 (12 MP + 12 MP)
- Battery: 3700 mAh
- OS: Android 13
- Weight: 187 grams (6.6 oz)
Review
We may receive a commission from Amazon for purchases made using the links below, but this has no bearing on our assessment methodology.
Full specifications
Detailed specifications, tests, and benchmarks of the Samsung Galaxy Z Flip 5Display
| Type | Dynamic AMOLED |
| Size | 6.7 inches |
| Resolution | 1080 x 2640 pixels |
| Aspect ratio | 21.9:9 |
| PPI | 425 ppi |
| Refresh rate | 120 Hz |
| Adaptive refresh rate | Yes |
| Max rated brightness | 500 nits |
| Max rated brightness in HDR | 1200 nits |
| HDR support | Yes, HDR10+ |
| Screen protection | Gorilla Glass Victus 2 |
| Screen-to-body ratio | 85.5% |
| Display features |
- DCI-P3
- Always-On Display |
| RGB color space | 97.3% |
| PWM | 120 Hz |
| Response time | 1 ms |
| Contrast | ∞ Infinity |
Design and build
| Height | 165.1 mm (6.5 inches) |
| Width | 71.9 mm (2.83 inches) |
| Thickness | 6.9 mm (0.27 inches) |
| Weight | 187 g (6.6 oz) |
| Waterproof | IPX8 |
| Advanced cooling | Vapor chamber |
| Rear material | Glass |
| Frame material | Metal |
| Colors | White, Black, Gray, Green, Purple, Yellow |
| Fingerprint scanner | Yes, in-button |
Performance
| Chipset | Qualcomm Snapdragon 8 Gen 2 |
| Max clock | 3200 MHz |
| CPU cores | 8 (1 + 2 + 2 + 3) |
| Architecture |
- 3 cores at 2 GHz: Cortex-A510
- 2 cores at 2.8 GHz: Cortex-A710 - 2 cores at 2.8 GHz: Cortex-A715 - 1 core at 3.2 GHz: Cortex-X3 |
| L3 cache | 8 MB |
| Lithography process | 4 nanometers |
| Graphics | Adreno 740 |
| GPU shading units | 2560 |
| GPU clock | 680 MHz |
| FLOPS | ~3481.6 GFLOPS |
Benchmarks
| CPU | 388586 |
| GPU | 222126 |
| Memory | 241250 |
| UX | 269260 |
| Total score | 1116662 |
Memory
| RAM size | 8, 12 GB |
| Memory type | LPDDR5 |
| Memory clock | 3200 MHz |
| Channels | 4 |
| Storage size | 256, 512 GB |
| Storage type | UFS 4.0 |
| Memory card | No |
Software
| Operating system | Android 13 |
| ROM | One UI 5.1.1 |
| OS size | 40 GB |
Battery
| Capacity | 3700 mAh |
| Max charge power | 25 W |
| Battery type | Li-Po |
| Replaceable | No |
| Wireless charging | Yes (15 W) |
| Reverse charging | Yes, (wireless) |
| Fast charging | Yes (55% in 30 min) |
| Full charging time | 1:19 hr |
| Web browsing | 08:59 hr |
| Watching video | 12:19 hr |
| Gaming | 03:56 hr |
| Standby | 94 hr |
Camera
| Matrix | 12 megapixels |
| Image resolution | 4000 x 3000 |
| Zoom | Digital |
| Flash | LED |
| Stabilization | Optical |
| 8K video recording | No |
| 4K video recording | Up to 60FPS |
| 1080p video recording | Up to 60FPS |
| Slow motion | 960 FPS (720p) |
| Angle of widest lens | 123° |
| Lenses | 2 (12 MP + 12 MP) |
| Wide (main) lens |
- 12 MP
- Aperture: f/1.8 - Focal length: 24 mm - Pixel size: 1.8 micron - Sensor: 1/1.76", Samsung S5K2LD (ISOCELL CMOS) - Phase autofocus (Dual Pixel) - Optical stabilization |
| Ultra-wide lens |
- 12 MP
- Aperture: f/2.2 - Pixel size: 1.12 micron - Sensor: 1/3.06", Sony IMX258 (Exmor-RS CMOS) |
| Camera features |
- Bokeh mode
- Pro mode |
| Samples | Photo samples of Samsung Galaxy Z Flip 5 from DxOMark |
| Megapixels | 10 megapixels |
| Image resolution | 3648 x 2736 |
| Aperture | f/2.2 |
| Focal length | 26 mm |
| Pixel size | 1.22 microns |
| Sensor type | ISOCELL CMOS |
| Sensor size | 1/3" |
| Video resolution | 2160p (4K) at 60 FPS |
DxOMark camera tests
Connectivity
| Wi-Fi standard | Wi-Fi 6E (802.11 a/b/g/n/ac/ax) |
| Wi-Fi features |
- Dual Band
- Wi-Fi MiMO - Wi-Fi Direct - Wi-Fi Hotspot - Wi-Fi Display |
| Bluetooth version | 5.3 |
| Bluetooth features | LE |
| USB type | USB Type-C |
| USB version | 3.2 |
| USB features |
- Charging
- USB-Storage mode - OTG |
| GPS | GPS, GLONASS, Beidou, Galileo, QZSS |
| NFC * | Yes |
| Infrared port | No |
| Number of SIM * | 1 |
| Type of SIM card | Nano |
| eSIM support * | Yes |
| Hybrid slot | No |
| LTE Cat * | 20 |
| 2G network | GSM 850, GSM900, DCS1800, PCS1900 |
| 3G network | UMTS B1(2100), B2(1900), B4(AWS), B5(850), B8(900) |
| 4G network | LTE B1(2100), B2(1900), B3(1800), B4(AWS), B5(850), B7(2600), B8(900), B12(700), B13(700), B17(700), B18(800), B19(800), B20(800), B25(1900), B26(850), B28(700), B32(1500), B66(AWS-3), B38(2600), B39(1900), B40(2300), B41(2500) |
| 5G support | Yes |
Sound
| Speakers | Stereo |
| Headphone audio jack | No |
| FM radio | No |
| Dolby Atmos | Yes |
Speakers test
Other
| Category | Flagship |
| Announced | July 2023 |
| Release date | August 2023 |
| SAR (head) | 0.6 W/kg |
| SAR (body) | 1.45 W/kg |
| Sensors |
- Hall-effect sensor
- Barometer - Proximity sensor - Gyroscope - Accelerometer - Ambient light sensor - Compass - Fingerprint |
| Bundled charger | Not included |
*
Disclaimer!
Some specifications of the Galaxy Z Flip 5 may differ by country or region
